G1/4 Solenoid operated 5/2 and 5/3 valves 4V series

4V200 Series

Benefits

  • Port size G1/4
  • Robust body made of aluminium alloy
  • Inline or manifold mounting

4V200 series 3D Files Download
4V200 series brochure pdf Download


3d model of the product

Download product card (pdf)

Technical details

Fluid

Air (to be filtered by 40 μm filter element)

Port size

G1/4 – exhaust port size G1/8

Orifice size

5/2 valves: 16,0 mm2 (Cv=0.89)

5/3 valves: 12,0 mm2 (Cv=0.67)

Power consumption

12 VDC and 24 VDC: 3,0 W

110/50 and 220/50 VAC: 4,5 va

24/50 VAC: 5,0 VA

Voltage tolerance

DC: ± 10% of nominal value

AC: ± 15% of nominal value

Operating pressure

1,5… 8,0 bar

Temperature range

-20… +70°C
